SIM800C Advantages:-
- Small size quad-band GSM/GPRS module
- LCC form factor, easy for solder
- Abundant software functions: DTMF, MMS, MUX
- Low Power consumption
- Embedded TCP/UDP protocols
SIM800C Features:-
- Frequency Bands: 850/900/1800/1900MHz
- GPRS multi-slot class: 12/10
- Dimensions: 17.6*15.7*2.3mm
- Weight: 1.3±0.1g
- Supply voltage: 3.4 ~ 4.4V
- Operation temperature:-40℃ ~85℃
- Compliant GSM phase 2/2+: Class 4 (2W @ 850/900MHz)
- Compliant GSM phase 2/2+: Class 1 (1W @ 1800/1900MHz)
- Control via AT commands (3GPP TS 27.007, 27.005 & SIMCom enhanced AT Commands)
- Low power consumption
- GPRS mobile station class B
SIM800C Interfaces:-
- Analog audio interface
- UART
- (U)SIM card(1.8V/3V )
- RTC
- ADC
- GPIO
- Antenna: GSM/BT*
